Interfaces

Defining an Interface​

An interface in OPC UA Modeler is defined using the interfaceTypes keyword. Each interface can have multiple components, each with a browseName, dataType, and modellingRule.

Here is an example of defining an interface called IVendorPlateType:

interfaceTypes:
  - browseName: IVendorPlateType
    components:
      - browseName: Manufacturer
        dataType: ua:LocalizedText
        modellingRule: Mandatory
      - browseName: SerialNumber
        dataType: ua:String
        modellingRule: Mandatory
      - browseName: Revision
        dataType: ua:LocalizedText
        modellingRule: Optional

Implementing an Interface at the Object Type Level​

To implement an interface at the object type level, you use the implementedInterfaces keyword within the objectTypes definition.

Here is an example of defining an object type called MySensorType that implements the IVendorPlateType interface:

objectTypes:
  - browseName: MySensorType
    subtypeOf: di:ComponentType
    implementedInterfaces:
      - browseName: IVendorPlateType

Implementing an Interface at the Component Level​

Interfaces can also be implemented at the component level, meaning that the component itself implements the interface. This is done using the implementedInterfaces keyword within the components definition.

Here is an example of defining an object type called MySensorType with a component called Identification that implements the IVendorPlateType interface:

objectTypes:
  - browseName: MySensorType
    subtypeOf: di:ComponentType
    components:
      - browseName: Identification
        typeDefinition: ua:FolderType
        implementedInterfaces:
          - browseName: IVendorPlateType

Promoting Optional Members to Mandatory at the interface implementation level​

For advanced use, it is possible to promote some optional members of the original interface to mandatory. This is done using the promotedToMandatory keyword within the implementedInterfaces definition.

Here is an example of promoting the Revision member to mandatory:

objectTypes:
  - browseName: MySensorType
    subtypeOf: di:ComponentType
    components:
      - browseName: Identification
        typeDefinition: ua:FolderType
        implementedInterfaces:
          - browseName: IVendorPlateType
            promotedToMandatory:
              - Revision

implementing an interface from another namespace​

Obviously, you can also implement an interface that has been defined into a other namespace by prefixing the browseName with the namespace alias.

namespaces:
  - di # import the device integration namespace
objectTypes:
  - browseName: MySensorType
    subtypeOf: di:ComponentType
    implementedInterfaces:
      # implement the IVendorPlateType interface from the di namespace
      - browseName: di:IVendorNameplateType
        # and turn the optional property of IVendorPlateType into mandatory in
        # our implementation
        promitedToMandatory:
          - di:Revision
          - di:Manufacturer
          - di:SerialNumber
